Lyngdorf SDA-2400 Power Amplifier

The Lyngdorf SDA-2400 includes both optical and coaxial digital inputs in addition to the traditional balanced and single-ended analog inputs in order to fit any possible setup.

This power amplifier can function in a traditional stereo or multichannel setupóbut also as a powerful addition to single standing media players and streaming devices with integrated volume control. Using the digital connections, there will be no interference or noise from external sources.

The inputs are based upon the Wolfson WM8804 PLL Transceiver for excellent dynamic performance and improved tolerance to clock jitter.

Lyngdorf is the pioneer in digital amplifiers, and the SDA-2400 power amplifier is not your typical Class D digital power amplifier. Itís better. It has very low and linear distortion and an impressive signal-to-noise ratio, making it the perfect choice for those seeking the purest sounding high-power amplifier on the market.

The output stage uses Pulse Width Modulation with a patented switch speed optimization technology. Together with a fixed switching speed of 390 kHz and minimal feedback control, this ensures low and linear distortion compared to typical Class D amplifiers.


Specifications

Power rating: 2 x 400 W @ 4Ohm, 2 x 200 W @ 8Ohm

Inputs:
1 x Analog Single Ended RCA
1 x Analog Balanced XLR
1 x Coaxial Digital (≤192kHz / 24 bit)
1 x Optical Digital (≤96kHz / 24 bit)
* All inputs have signal detection

Power modes: Input detection, Always on
Trigger (12V): 1 x Input, 1 x Output for daisy chain

Dimensions: (WxHxD) 45 x 7.3 x 36 cm*
17.7 x 2.9 x 14.2 in*
*including 1.3cm / 0.5in feet.

Finish: Anodized aluminum, matte black

Weight: 6.5 kg 14.3 lb
